1. Precise Flow Control : The design of the globe valve allows for precise regulation of fluid flow, making it suitable for applications where accurate control and modulation are critical.

2. Versatility in Applications : Globe valves find applications in various industries, including water treatment, power generation, oil, and gas, and more, thanks to their adaptability and effectiveness in controlling different types of fluids.

3. Excellent Shut-Off Capability : Globe valves provide a reliable shut-off mechanism, ensuring minimal leakage when fully closed. This feature is essential for applications where preventing fluid escape is crucial.

4. Bidirectional Flow Control : The bidirectional flow capability of globe valves adds to their versatility, allowing for installation in pipelines where the direction of fluid flow may change.

5. Durable Construction : Globe valves are typically robustly constructed, ensuring longevity and reliability in a variety of industrial settings. Materials like stainless steel and cast iron are commonly used for their durability and corrosion resistance.

In summary, the globe valve's distinctive design and precise flow control make it a valuable component in fluid systems across industries. Its ability to modulate flow, coupled with reliable shut-off capabilities, positions the globe valve as an essential tool for maintaining efficiency and control in various industrial processes.

Design : : Globe Valve design complies to API 623 along with its wall thickness requirements.

Universal trim : 13Cr stem, 13Cr faced disc, and CoCr alloy faced seats – API Trim 8 suitable for service up to 850°F (454°C).

Seat face : CoCr alloy hard-faced, ground, and lapped to a mirror finish. Conical seat machined to fine surface finish.

Body Guided disc accurately mates the hard-faced surface of the disc (hard-faced with 13Cr, CoCr alloy, SS 316, or Monel) with the surface of the body seat, which is ground and lapped to a mirror finish.

Body and bonnet castings are precision machined. One-piece bonnet for better alignment, fewer parts.

Stuffing box machined to fine surface finish.

Body and bonnet joint accurately machined to fine surface finish. Fully enclosed gasket.

Yoke Sleeve (Rotating stem nut) is Austenitic A439 Gr. D-2, renewable in-line.

Handwheels : Globe valves require higher closing torques than gate valves with the same seat diameter and pressure class. Accordingly, Globe Valves are supplied with handwheels suitable to generate required torque seamlessly.

Flanges :
ASME Classes: 150–300: 1⁄16” raised face
ASME Classes: 600–1500: ¼” raised face
Finish: 125–250 AARH for all valves
